| Dimensions |
406 x 206 x 450mm (DWH) |
Form Factor |
Mid Tower |
Materials |
Steel + Plastic |
Mainboard Support |
E-ATX, ATX, Micro-ATX, ITX |
Front Access & Controls |
Power, Reset, USB 2.0 x2, USB 3.0 x 1, Headphone/Mic Combo Jack |
Side Panel |
Tempered glass |
Expansion Slots |
7 |
Expansion & Drive Bays 3.5″ /2.5″ |
2 / 1 |
Expansion & Drive Bays 2.5″ |
2 |
Fan Support Front |
3 x 120 / 2 x140mm |
Fan Support Top |
2 x 120 / 2 x140mm |
Fan Support Power Supply Shroud |
2 x 120mm |
Fan Support Rear |
1 x 120mm |
Included Fan(s) |
3 x 120mm fixed mode RGB fans in front & 1 x 120mm regular fan in rear (NX292) 3 x 120mm ARGB fans in front & 1 x 120mm ARGB fan in rear (NX292 ARGB) |
Radiator Support Front |
120 / 140 / 240 / 280 / 360mm |
Radiator Support Rear |
120mm (Length ≤ 156mm) |
Max GPU Length |
≤ 320mm |
Max CPU Cooler Height |
≤ 155mm |
Max PSU Length |
≤ 165mm(with HDD) ≤ 300mm(without HDD) |
Dust Filter |
Top / Bottom |
Net Weight |
4.5KG (NX292) / 4.89 Kg (NX292 ARGB) |
Gross Weight |
5.3KG (NX292) / 5.85 Kg (NX292 ARGB) |
